User Manual of EM730/EM730E Series Inverter
11
★
Correct selection of the inverter: The rated output current of the inverter is greater than or
equal to the rated current of the motor, taking into account the overload capacity.
★
The difference between the rated power of the inverter and that of the motor is usually
recommended not to exceed two power segments.
★
When a high-power inverter is provided with a low-power motor, the motor parameters
must be entered accurately to prevent the motor from damage as a result of overload.
The technical specifications of the EM730/EM730Eseries inverter are shown in Table 1-2.
Table 1-2 Technical Specifications of EM730/EM730E Series Inverter
Rated voltage of
power supply
Three-phase 340V-10% to 460V+10%,
Single-phase/three-phase 200V-10% to 240V+10%;
50-60Hz ± 5%; voltage unbalance rate: <3%
The maximum output voltage is the same as the input power
voltage.
Continuous output of 100% rated current
150% heavy-duty rated current: 60s; 180% heavy-duty rated
current: 10s; 200% heavy-duty rated current: 2s
120% light-duty rated current: 60s; 150% light-duty rated
current: 10s; 180% light-duty rated current: 2s
V/F control (VVF); speed sensorless vector control (SVC)
Frequency (speed) input, torque input
Start and stop control
mode
Keyboard, control terminal (two-line control and three-line
control), communication
0.00~600.00Hz/0.0~3000.0HZ
Input frequency
resolution
Digital input: 0.01Hz/0.1Hz
Analog input: 0.1% of maximum frequency
Rated synchronous speed ± 0.2%
