26
3.4.7 Description of icons of idle screen
1
） These icons mean the EVSE has connected to 4G/Ethernet/Bluetooth/WiFi
2
） These icons mean the EVSE has connected to 4G/Ethernet/Bluetooth/WiFi and the platform.
3
） These icons mean the EVSE fails to connect to 4G/Ethernet/Bluetooth/ WiFi
