Attachment
3.5
stroke.
Loosen screw '2' and hold needle
'1' with its indented part 'A' facing
exactly to the right in direction 'B'.
Figure 10
Cautions
Figure 11
Choose a proper
needle size according
to the count of thread
and the type of sewing
material used.
The power supply
should be cut off
before attaching the
needle.
Machine
Threading
3.6
Insert the needle in the direction of
the arrow until it will go no further.
Tighten the screw '2'.
Make sure the long groove
'C' of the
needle is facing exactly to the left in
direction 'D'.
When threading the machine, the
est point of its stroke.
shown below.
long in the needle.
1
C
A
B
D
2
1
3
Leave thread approximately 4.0 cm
Threading the machine in the order
needle bar should be at the high-
Turn the hand wheel until the needle
bar reaches the highest point of its
4
8
10
11
9
Needle
2
5
6
7
9
| Instruction Manual and Parts List
