High Speed Overlock Machine | Instructions Manual and Parts List
Machine
Installation
Setthe machine headon the sup-
portbase.
Connectthemachinewheeltothe
motorwiththebelt.
Adjustthebelttensionsothatthere
isagapofabout20mmwhenthe
centerofbeltispressured.
Setthebeltcoveraccordingtog-
ure4.
Figure 3
Figure 4
Install the friction motor pedal at
therightsideandthepedalofthe
presserlifterattheleftside.
Besurethe motorisclockwise di-
rected,referredtogure3.
3.2
