30
High Speed Overlock Machine | Instructions Manual and Parts List
6.6
Thread Guide
Components
1 20111013 Thread tension nut 3 4 4
20311002 Thread tension nut 3 4 4
2 20111014 Ratchet 3 4 4
3 20127018 Thread tension spring 1 2 2
4 20127019 Thread tension spring 1 1 1
5 20127020 Thread tension spring 1 1 1
6 20111015 Thread tension disc presser 3 4 4
7 20112057 Thread tension disc 6 8 8
8 20123018 Thread tension disc washer 3 4 4
9 201S30016 Thread tension screw 3 4 4
10 20113001 Thread guide 1 2 2
20213001 Thread guide 1 2 2
11 20113002 Thread guide 2 2 2
20213002 Thread guide 2 2 2
12 20113003 Upper thread take-up 1 1 0
20113004 Upper thread take-up 0 0 1
Qty
No. Part No. Description 3 4 5
thread thread thread
