Qty
No. Part No. Description 3 4 5
thread thread thread
29
High Speed Overlock Machine | Instructions Manual and Parts List
6.5
Needle Bar
Components
1 20102002 Needle bar driving frame rock shaft 1 1 1
2 20126007 Eccentric shaft 1 1 1
3 20103004 Needle bar shaft bushing back 1 1 1
4 20108001 Thrust collar 1 1 1
5 20104001 Needle bar driving crank 1 1 1
6 20122022 Oil seal 1 1 1
7 B07006 Needle bearing 1 1 1
8 20128004 Washer ring 1 1 1
9 20126008 Needle bar guide pin 1 1 1
10 20123021 Oil wick 1 1 1
11 20102003 Needle bar rock shaft 1 1 1
12 20103005 Needle bar shaft bearing (left) 1 1 1
13 20122021 Seal ring 2 2 2
14 20103006 Needle bar shaft bearing (right) 1 1 1
15 20108002 Thrust collar 2 2 2
16 20101013 Balance block 1 1 1
17 20104002 Needle bar frame rock shaft crank 0 1 0
20104003 Needle bar frame rock shaft crank 1 0 1
18 20105001 Needle bar connecting rod 1 1 1
19 20126009 Connecting link pin 1 1 1
20 201S12005 Screw 1 1 1
21 20101014 Needle bar guide bracket 1 1 1
22 2010200400 Needle bar 1 1 1
23 20117012 Cat No. 6120-06 Needle 1 2 0
20117013 Cat No. 6120-06 Needle 0 0 2
20117014 Cat No. 6120-06 Needle 0 0 2
24 20123021 Oil wick 1 1 1
25 20121020 Plastic tube 1 1 1
26 20123005 Oil wick 2 2 2
27 20134002 Needle clamp 1 0 0
20134001 Needle clamp 0 1 0
20134003 Needle clamp 0 0 1
20134004 Needle clamp (for thick) 0 0 1
28 201S15003 Thrust collar set screw 2 2 2
29 201S13003 Hexagon socket screw 1 1 1
30 201S30003 Balance block position screw 2 2 2
31 201S14002 Thrust collar set screw 3 3 3
32 201S20006 Needle bar connecting rod set screw 2 2 2
33 201S11026 Screw 1 1 1
34 201S17001 Screw 1 1 1
35 201S17004 Screw 1 1 1
36 S01022 Screw 1 1 1
37 S010005 Screw 4 4 4
38 H05008 Snap ring 1 1 1
39 201S14001 Screw 2 2
