Qty
No. Part No. Description 3 4 5
thread thread thread
23
High Speed Overlock Machine | Instructions Manual and Parts List
6.2
Cloth Plate
Components
1 2011207900 Cloth plate 1 1 0
2 20122012 Rubber bushing 1 1 1
3 20122013 Rubber bushing 1 1 1
4 201S30011 Screw 1 1 1
5 20127003 Spring 1 1 1
6 20112011 Cloth plate slider cover 1 1 1
7 20127004 Cloth plate cover spring 1 1 1
8 20111022 Cloth plate lower plate 1 1 0
9 20111003 Washer 1 1 1
10 20112012 Upper looper sealing plate 1 1 1
11 20122015 Upper looper sealing plate washer 1 1 1
12 201S11018 Screw 1 1 1
13 201S11016 Screw 2 2 2
14 201S20003 Screw 1 1 1
15 201S17004 Screw 2 2 2
16 201S16003 Nut 1 1 1
17 201S30007 Screw 1 1 1
18 201S16001 Nut 1 1 1
19 W01005 Washer 3 2 2 2
20 201S11005 Screw 2 2 2
21 201S11037 Screw 3 3 3
22 20128019 Washer 3 3 3
23 2011200500 Cloth plate 0 0 1
24 20111002 Cloth plate lower plate 0 0 1
25 20122011 Rubber bushing 1 1 1
