Qty
No. Part No. Description 3 4 5
thread thread thread
27
High Speed Overlock Machine | Instructions Manual and Parts List
6.4
1 20102001 Main shaft 1 1 1
2 20111008 Wheel 1 1 1
3 20101008 Rear shaft bearing cover 1 1 1
4 20122019 Washer 1 1 1
5 20128002 Main shaft spring washer 1 1 1
6 20103002 Oil seal 1 1 1
7 O01003 Seal ring 1 1 1
8 B03001 Bearing 2 2 2
9 20125001 Oil pump worm 1 1 1
10 20129001 Snap spring 1 1 1
11 20103003 Main shaft left bushing 1 1 1
12 B04001 Bearing 1 1 1
13 20101009 Bearing cover 1 1 0
20101010 Bearing cover 0 0 1
14 20122020 Bearing cover washer 1 1 1
15 20101044 Pulley 1 1 1
16 20101012 Key 1 1 1
17 20126006 Bulgy pulley shaft 0 0 1
18 30128008 Washer 1 1 0
19 201S11040 Screw 1 1 0
20 201S11034 Screw 1 1 1
21 20128024 Washer 1 1 1
22 201S15004 Screw 2 2 2
23 201S11016 Screw 3 3 3
24 201S14002 Screw 1 1 1
25 201S11012 Screw 3 3 3
26 201S15005 Screw 2 2 2
27 201S15001 Screw 1 1 1
Main Shaft
Components
