12
Changing screw-on presser feet (H)
• Raise needle and presser foot.
• Loosen presser foot screw (1) and remove
presser foot with shank (2), guiding it toward
you and to the right.
• To replace presser foot with shank, hook
shank around the presser bar and tighten
presser footscrew with the use of a coin.
Attaching the feed cover (F)
The feed cover is used to keep the feed from
moving the fabric when attaching a button,
darning or sewing free-motion embroidery. To
attach it, follow the directions below:
• Raise needle and presser foot.
• Open slide plate.
• Slide feed cover on top of needle plate,
pressing tabs (1) and (2) into holes.
• Close slide plate.
• To remove, open slide plate and lift front
edge of cover; pull it away.
