Singer 7464 - Needle Position at Zigzag Stitching; Zigzag Needle Position Checking; Zigzag Needle Position Adjustment

- 14 -
Sec. 5 Needle position at zigzag stitching
 Checking:
1. Set test mode at 1.
2. Turn hand wheel by hand and see if needle leaves the same clearance at both right
and left end of needle plate hole.
Adjustment:
1. Loosen hex screw (A) and adjust needle position by turning eccentric pin using 7mm
wrench.
b
a
a＝b
A
