- 17 -
Sec. 7 Needle timing to feed dog

Note: After adjustment, be sure to follow “Needle timing to shuttle”.
Checking:
1. Turning hand wheel, bring needle bar to it’s highest position.
2. Check to see if feed dog starts to move when needle starts to go down by
turning hand wheel towards you.
Adjustment:
1.
Adjust the angle of timing gear to lower shaft with 2 screws on timing gear loosened and hex
driver inserted into one of the screws by turning main shaft with hand wheel,.
If feed-dog motion too early → Turn hand wheel towards you.
If feed-dog motion too late → Turn hand wheel away from you.
2. Tighten screw temporarily and check feed-dog motion.
Feed dog starts to move
almost at the same time
when needle starts to go
down.
