Switch Board – 4 (for 7428 ＊7436)
Component number is
87564 for 7428, *87578 for *7436.
Be sure to check number printed on board.
Revised: January, 2006
13P Connector
Connect with CPU
4P Connector
Connect with CPU
4P Connector
Connect with CPU
Twin needle select
SW & needle stop
select SW
64
12 Switches
