- 53 -
Switch Board – 5 (for 7448 and 7468)
Component number is
87548.
Be sure to check number printed on board.
13P Connector
Connect with CPU
4P Connector
Connect with CPU
4P Connector
Connect with CPU
12 Switches
Twin needle
Select SW
Needle stop position
select SW
