A color coded threading diagram is located inside
the looper cover for quick reference.
Thread the machine in the order 1 to 4 as shown.
1. Upper looper thread……… Orange
2. Lower looper thread……… Yellow
3. Right needle thread............ Green
4. Left needle thread...........… Blue
Caution:
Be sure to turn off power switch.
Thread the upper looper as indicated 1 ~ 8.
Pass thread from back to the front through the
thread guide 1 .
1) Threading the Upper Looper (Orange)
11. THREADING THE MACHINE
Threading Diagram
Understanding the Color Code
To Thread the Machine Correctly
12
Presser Foot needs to be up before theading.
You MUST rethread all 4 threads, if one breaks.
