Preparations – 13
English
Important! Make sure that the presser foot is raised and the
needle is in its highest position by turning the handwheel
toward you. This is very important to help ensure that the
machine is correctly threaded. Not doing so can result in poor
stitch quality when you start to sew.
1. Place the thread on the spool pin and t the appropriately
sized spool cap.
2. Pull the thread into the thread guide (A) from front to the
back and thread guide (B) from back to front. Pull the
thread between the tension discs (C).
3. Continue bringing the thread down through the right thread-
ing slot, around the U-turn, then back upwards through the
left threading slot.
4. Bring the thread from the right into the take-up lever (D)
and down in the left-hand threading slot, into the lower
thread guide (E) and to the needle thread guide (F).
5. Thread the needle from front to back.
Thread the Machine
Machine from above
Machine from front
