Singer S0100 - Feed Dog Height

18 S0100 / S0105 104 73 97-26
11. Feed dog height
CHECK
Turn the hand wheel in sewing direction so the top of rear feed dog teeth is level with the
needle plates top surface, then should also the front feed dog teeth be level with the needle
plates top surface.
ADJUSTMENT
1. Turn the hand wheel in sewing direction so the top of rear feed dog teeth is level with
the needle plates
top surface.
2. Loosen up the screw (A) on the front feed dog.
3. Move the front feed dog so it becomes level with the needle plates top surface.
4. Tighten screw (A).
A
