Singer S0100 - Clearance between Rear Needle Support and Needle

22 S0100 / S0105 104 73 97-26
Right hand needle
15. Clearance between rear needle support and needle
CHECK
When Lower looper is behind the left needle, the clearance between rear needle support and
left needle should be 0 - 0.03 mm.
Valid for #90 needle.
ADJUSTMENT
1. Turn screw (A) of the needle support and turn it until its clearance to the needle is
0 - 0.03 mm.
2. Make sure the screw is secured with equivalent adhesive.
0-0.03 mm
A
A
