Singer S0100 - Presser Foot Height

104 73 97-26 S0100 / S0105 25
18. Presser foot height
Check
When the presser foot is in it’s highest position the distance between the needle plate
and the presser foot should be 4.7 mm.
Adjustment
1. Loosen the screw (A).
2. The presser bar height can now be adjusted up or down until the distance is
4.7 mm between the presser foot and the needle plate.
3. Tighten the screw (A).
4.7 mm
