© Nov. 2022 6-2 GTZZ15J Operation Manual
PRE-OPERATION FUNCTION TEST
Figure 6-1
Table 6-1
1. Display screen
(see the figure and table below)
9. Engine speed select switch
17. Ground/Platform select switch
2. Key switch 10. Engine start engine 18. Platform control position
3. Horn
11. Glow plug switch (if equipped) 19. Ground control position
4. Emergency power switch
12. Turntable rotation switch
20. ON position
5. Enable switch
13. Platform leveling switch 21. OFF position
6. Main boom luffing switch 14. Jib boom up/down switch
7. Articulated boom luffing switch 15. Main boom telescoping switch
8. Turntable rotation switch
16. Emergency stop button
OFF
ON
1
3
2
5
4
6
9
10
12
14
15
17
16
20
19
21
18
11
13
7
8
