PRE-OPERATION FUNCTION TEST
GTZZ15J Operation Manual 6-3 © Nov. 2022
Figure 6-2 Ground controller display screen
Table 6-2
1. Current work hours
13. Low diesel/battery alarm 25. Engine high idle
2. Platform load
14. Engine oil pressure alarm 26. Engine low idle
3. Battery gauge 15. Low battery alarm 27. Operating position
4. Accumulated work hours
16. Water temp alarm 28. Non-operating position
5. Tachometer 17. Converter ON 29. Boom horizontal reach
6. Setup menu
18. Not used
30. Boom angle above horizontal
7. Machine info 19. Chassis tilt alarm
31. Boom length
8. Turntable info 20. Platform tilt alarm
32. Platform height
9. Platform info
21. Heavy load indicator
33. Overload limit
10. Alarm message
22. Overload alarm
34. Drive limit (operating position)
11. Fault alarm 23. Not used
35. Drive and boom functions
allowed
12. Glow plug
24. Not used
33
E
20
40
60
80
F
60 %
2.40 m
9.92 m
2.44 °
10.92 m
0
1
2
3
4
5
0
RPM
X1000
H H
11.5
0011.5
32
15
1 2
6
5
7
4
10
1112
9
13
8
14
3
20 1925 24 1622 172123 182627
30
28
29
31
KG
33
DR
D/B
34
35
FE
