TB18 Plus&20J Plus Operation Manual 1-1 © Apr 2022
1 MACHINE SPECIFICATIONS
Table 1-1 TB18 Plus specifications
MEASURE
TB18 Plus (METRIC) TB590 Plus (IMPERIAL)
DIMENSION
Max platform height
18.1 m 59ft 5in
Max working height
20.1 m 65ft 11in
Max horizontal reach 15.5 m 50ft 10in
Overall length (stowed)
8.93 m 29ft 4in
Overall width (stowed)
2.49 m 8ft 2in
Overall height (stowed)
2.77 m 9ft 1in
Wheelbase 2.49 m 8ft 2in
Ground clearance 0.46 m 1ft 6in
Tire size (spec / type)
Options
36×14-20 (non-marking)
36×14-20 (solid)
355/65D625 (foam-filled)
Platform dimension (L×W×H)
Options
1.45×0.85×1.1 m
1.83×0.85×1.1 m
2.44×0.91×1.1 m
Options
4ft 9in×2ft 9in×3ft 7in
6ft×2ft 9in×3ft 7in
8ft×3ft×3ft 7in
PERFORMANCE
Rated platform capacity (restricted/
unrestricted)
454 kg
1000 lb
Max number of occupants
(restricted/unrestricted)
3 persons
Turntable rotation / continuous 360°/ continuous
Platform rotation 160°
Max drive speed (stowed)
4.8km/h
3 mph
Max drive speed (raised)
1.1 km/h
0.68 mph
Drive mode (drive×steer)
4WD×2WS
Gradeability
45%/24°
Turntable tailswing
1.45 m
4ft 9in
Max allowable inclination 5°
Turning radius (inside)
2.4 m 7ft 10in
Turning radius (outside)
5.55 m 18ft 3in
Max allowable side force 600 N 135 lbf
