© Apr 2022 1-4 TB18 Plus&20J Plus Operation Manual
MACHINE SPECIFICATIONS
Table 1-2 TB20J Plus specifications (continued)
MEASURE
TB20J Plus (METRIC) TB660J Plus (IMPERIAL)
IP rating
IP65
POWER
Engine (rated power/rated rpm/
spec/brand/emission standard)
43kW/2500rpm/QSF2.8t3NA60/Cummins/China Phase 3
36.4kW/2600rpm/D2.9 L4/Deutz/EU Phase 5
36.4kW/2600rpm/D2.9 L4 T4f/Deutz/EPA Phase 4
55.4kW/2400rpm/TD2011 L04i/Deutz/Tier 3
36.8kW/2500rpm/WP3.2/WEICHAI/China Phase 4
Hydraulic tank capacity
190 L
41.8gal (Imperial)/50.2gal (US)
Fuel tank capacity
160 L
35.2gal (Imperial)/42.3 gal (US)
Hydraulic system pressure 28 MPa 4061 Psi
Battery (number×voltage, capacity) 2×12V, 110Ah
Power system voltage
12 VDC
Control system voltage 12 VDC
GROUND BEARING DATA
Max tire load
6740 kg
14859 lb
Pressure against ground
674 kPa 97.8 Psi
ENVIRONMENT
Max allowable wind speed 12.5 m/s 28 mph
Max allowable altitude 1000 m 3280 ft
Allowable ambient temperature
(lead-acid battery)
-10℃～40℃ 14℉～104℉
Allowable ambient temperature (-
lithium battery)
-20℃～40℃ -4℉～104℉
Max allowable RH 90%
Storage environment
Stored at -20℃ to 50℃ (-4℉ to 122℉) in a well-ventilated environment with
90% relative humidity (20℃ [68℉]), and away from rain, sun, corrosive
gas, inflammables and explosives.
WEIGHT
Gross weight (unladen) 11900 kg
26235 lb
Note:
a) The platform height plus the operator height (taken as 2m [6ft7in]) is the working height.
b) The ground bearing data is approximate value, not factoring the different options, thus it is applicable only in adequately
safe conditions.
c) In different areas, hydraulic oil, engine oil, coolant, fuel and lubricant should be added in accordance with the environmental
temperature.
d) In cold weather, auxiliary devices are needed to start the machines.
e) Rated platform capacity represents the rated load of the platform, including the loads of persons, materials, tools, platform
accessories and other objects borne by the platform.
