© Apr 2022 7-8 TB18 Plus&20J Plus Operation Manual
OPERATING THE MACHINE
1. Use a carpenter’s level, a straight piece of wood (at
least 1 m [3.3 ft] long) and a tape measure.
2. Measure the height H and length/distance L of the
slope.
Figure 7-5
3. Slope grade= H/L x 100%.
NOTICE
The machine must not drive for over 2min on the
maximum permissible slope grade to prevent the
tires running suspended.
