Sinterit LISA X User Manual | 4
1. Printer overview
1
LID HANDLE
14
RECOATER
6
E-STOP (EMERGENCY STOP PUSHBUTTON)
5
SCREEN
8
DOOR
9
OVERFLOW
CONTAINER
7
FEED BED
PRINT BED
12
4
PRINTER LID
11
RESET BUTTON
10
USB PORT
2
SPLIT PIN
3
HEATING MODULE
15
INFRARED BULB
13
RECOATER GUIDE BAR
Fig. 1.1 View of the front of the printer, heating module, print chamber, and overow container.
16
PYROMETER
WINDOW
Fig. 1.2 View of the pyrometer window.
