Instruction for work

1.3 Technical data

Type

SPIDER 400/4 ALP

Rotating heads 4

No. of tines / rotor 24

Working capacity to 4 ha/h

Working width to 4,0 m

Transport width 2,41 m

Machine width 4,53 m

Height 1,3 m

Length 1,6 m

Working speed to 12 km/h

Mass 390 kg

Necessary tractor

power

13 KW

Output shaft revolutions 540 (rpm)

Rotating head

revolutions at 540 rpm:

205 (rpm)

Tyres 15x6.00-6

link Fixed (movable)

Hitch frame

movable in three

points

Frame hydraulic

Cardan shaft:

- length between the

joints:

1000 mm

- safetycoupling

600 Nm
