SPIDER
11
12
10
11
9
1
3 2
4 7
8
5 6
1. Side rotor
2. Spring tine arm
3. Spring tine
4. Support wheel
5. Support leg
6. Protection rail
7. Protection of the PTO shaft
8. Hydraulic hose
9. Hydraulic cylinder
10. Rotor hold/for transport position
11. Pull cord
12. Gear joint
