Sipromac 350 - Page 29

MACHINE
PART
ITEM
MAT.
CNC
DWG BY
APP. BY
DATE
DATE
QTY.
DEPT.
SIPROMAC
ST-GERMAIN DE GRANTHAM
QUEBEC CANADA
DEPT. TOL.
USINAGE
TOLERIE
SOUDAGE
METRIC
± 0.1
± 0.5
± 0. 5
INCH
± 0.004"
± 0.020"
± 0.020"
N.T.S.
NO.
004A4112
SBU
4
M
VACUUM TABLE
NSF FOOT
13-09-20
004A4112
LET. MODIFICATION DATE INT.
1
ITEM PART # DESCRIPTION QT.
1 002A3528 NSF FOOT 1
2 051-0288 BOLT 1/4-20 x 3 1/2" S/S 1
3 051-0740 WASHER 1/4" FLAT S/S 1
4 051-0581 NUT 1/4"-20 NYLON LOCK S/S 1
4
3
2
