15
Drill 4 x 6mm holes through the template as shown in the diagram and fit the Rawlplugs and screw eyes
supplied.
Note: In some instances the plastic Rawlplugs supplied my need to be substituted with fibre
Rawlplugs, if the appliance is likely to heat the screw eyes.
If the fireplace does not allow for the exact layout shown, the eyebolts should be fixed to give a similar
configuration as possible.
Thread the tensioning cable through the holes at the top of the firebox, then through the two screw eyes
in the top position and then through the one at the lower position, back through the lower hole in the
firebox as shown in the diagram.
