Sirona c8+ turn - C8+ Turn Unit Dimensions (1:20 Scale)

2 Dimensions, technical data Sirona Dental Systems GmbH
2.4 C8
+
Turn 1:20 Installation Requirements C8
+
/C8
+
Tu r n
60 28 000 D3417
24 D3417.021.04.11.02
Recommended distances from cabinet or wall
2.4 C8
+
Turn 1:20
Hazard warning:
The lamp installed here and the dentist
element have a swivel range which ex-
ceeds the specified distances!
Center of floor opening
1600
63”
1600
63”
2500
98 7/16”
250
9 7/8”
250
9 7/8”
