Sirona Dental Systems GmbH 2 Dimensions, technical data
Installation Requirements C8
+
/C8
+
Tu r n 2.4 C8
+
Turn 1:20
60 28 000 D3417
D3417.021.04.11.02 25
English
Minimum distances for conversion from right-handed
to left-handed treatment center and vice versa
2700x2650mm
C8
+
Turn 1:20
Center of floor opening
1050
41 3/8”
1050
41 3/8”
2750
108 1/4”
1600
63”
1234
48 1/2”
1600
63”
Cabinet on the
right or left
max. height:
900mm
250
9 7/8”
250
9 7/8”
