2 Dimensions, technical data Sirona Dental Systems GmbH
2.4 C8
+
Turn 1:20 Installation Requirements C8
+
/C8
+
Tu r n
60 28 000 D3417
26 D3417.021.04.11.02
Minimum distances for conversion from right-handed
to left-handed treatment center and vice versa in
narrow spaces 3650x2100mm
C8
+
Turn 1:20
1050
41 3/8”
1050
41 3/8”
Center of floor opening
3650
143 3/4”
2134
84”
1250
49 1/4”
Installation area
max. 900mm high
250
9 7/8”
250
9 7/8”
