Sirona Dental Systems GmbH 2 Dimensions, technical data C8
+
/ C8
+
Turn 1:20
Installation Requirements C8
+
/C8
+
Tu r n 2.4 C8
+
Turn 1:20
60 28 000 D3417
D3417.021.04.11.02 27
English
Identical working conditions for right-handed and
left-handed operators:
Position for right-handed operators
C8
+
Turn 1:20
Center of floor opening
1050
41 3/8”
1050
41 3/8”
1600
63”
1600
63”
17°
2750
108 1/4”
1234
48 1/2”
250
9 7/8”
250
9 7/8”
