2 Dimensions, technical data C8
+
/ C8
+
Turn 1:20 Sirona Dental Systems GmbH
2.4 C8
+
Turn 1:20 Installation Requirements C8
+
/C8
+
Tu r n
60 28 000 D3417
28 D3417.021.04.11.02
Identical working conditions for right-handed and
left-handed operators:
Position for left-handed operators
C8
+
Turn 1:20
Center of floor opening
1050
41 3/8”
1050
41 3/8”
1600
63”
1600
63”
17°
2750
108 1/4”
1234
48 1/2”
250
9 7/8”
250
9 7/8”
