What to do if Sirona Dental equipment shows a Command error?
If you encounter a 'Command' error with your Sirona Dental equipment, first restart the unit and perform the self-test again. If the problem persists, check the connecting cable L83 between board DX1 and the sensor unit. If necessary, replace board DX11 or the sensor unit.
Why does Sirona Dental equipment show a timeout error?
If the Sirona Dental equipment self-test could not be completed within 20 seconds, it indicates a timeout issue.
What to do if Sirona Dental equipment shows a Prep error?
If you encounter a 'Prep' error with your Sirona Dental equipment, check the connecting cable L83 between board DX1 and the sensor unit. If the problem persists, replace board DX11 or the sensor unit.
What to do if Sirona Dental equipment shows a Transfer error?
If you encounter a 'Transfer' error with your Sirona Dental equipment, check the connecting cable L83 between board DX1 and the sensor unit. If the problem persists, replace board DX11 or the sensor unit.
General| Brand | Sirona |
|---|---|
| Model | ORTHOPHOS SL 3D |
| Category | Medical Equipment |
| Language | English |
Warns about shock hazards when replacing parts or working with power supply components.
Details dangers of incorrect fixed electrical connections, emphasizing regulatory compliance.
Details observation of radiation regulations and positioning of personnel during exposures.
Lists specifications for the ORTHOPHOS XG 3D/Ceph unit, including voltage, current, and dimensions.
Guides on configuring the X-ray component for network acquisition, including IP settings.
Provides instructions for updating the unit's firmware using SIDEXIS 4.
Covers procedures for managing sensor data via the Sirona Web service.
Details error codes (Ex yy zz) and their classifications for troubleshooting.
Provides a comprehensive list of error codes sorted by location.
Provides procedures for checking CAN bus connections and components.
Troubleshooting steps for excessive device leakage current.
Guides through diagnosing errors related to the X-RAY control signal path.
Provides step-by-step guidance for performing adjustments and calibrations.
Explains how to access and perform service routines using the control panel.
Covers procedures for updating module software versions and confirming serial numbers.
Explains dosimetry procedures with a dosimeter.
Provides routines for checking and managing the CAN bus.
Covers unit configuration options like hardware version and language.
Provides routines for setting and checking height adjustment limits.
Covers self-tests for DCS and FP image data paths.
Provides routines for calibrating ceph sensor and diaphragm axes.
Covers displaying and setting network data like IP addresses.
Mandates checks like circuit breaker and leakage current tests after repairs.
Detailed instructions for replacing the height adjustment motor and spindle.
Procedures for replacing the ring motor and its pinion.
Guides for replacing pan actuators, including cable routing.
Procedures for replacing the user interface and the entire control panel.
Covers replacement and adjustment of FH and MS laser light localizers.
Steps for replacing the diaphragm unit and post-replacement checks.
Detailed instructions for replacing the X-ray tube assembly and its fan.
Covers replacement of Flat Panel Detectors and DCS sensors.
Important notes and procedures for replacing internal boards like DX1, DX11, DX32.
Procedures for checking tube voltage, current, fan, and radiation time.
