SIRS NAVIGATION LTD
COMPONENT MAINTENANCE MANUAL
CLEANING
1. General
Items necessary for the cleaning procedures are detailed in Table 4001 below.
Nomenclature Vendor
Silicone fluid (Viscosity 3 cs ± 10%).
Electrical Cleaner (Ambersil FE10)
NATO Code: 6850-99-6636478
Grease (DTD 5598 or Castrol LM)
Lint free cloth
‘Peg-wood’ stick
Small Brush
SIRS Navigation Ltd,
Commercially available
Cleaning Agents
Table 4001
2. Procedure
WARNING: OBEY ‘HEALTH AND SAFETY DATA SHEETS’ FOR ALL
CLEANING MATERIALS.
A. Stem Assembly (80)
(1) Clean in ‘Electrical Cleaner’ and dry in a jet of clean, dry air.
(2) Polish the ‘sapphire cup’ with the end of a ‘peg wood’.
B. Corrector Assembly (160)
(1) Spray Gear Components with Electrical cleaner.
NOTE
: Do not let electrical cleaner contact the label (270).
(2) Dry in a jet of clean, dry air.
(3) Lightly lubricate the corrector gear spindles with grease.
PAGE 4001
APR 10/03
34-25-21
