SIRS Navigation KCA0101C - Illustrated Parts List

SIRS NAVIGATION LTD
COMPONENT MAINTENANCE MANUAL
STANDBY COMPASS - ILLUSTRATED PARTS LIST
WARNING: ONLY USE SPARES AND COMPONENTS SPECIFIED BY
SIRS NAVIGATION LTD.
1. Ordering
Spares must be ordered with reference to the part number specified in the illustrated
parts list.
A certificate of release must be supplied with each component ordered.
Components that can deteriorate, including rubber items, must provide the
manufacture date and shelf life.
2. General
The illustrated parts list gives information and identification of replaceable parts and
assemblies of units specified in this manual.
The abbreviation used for British Associated screw threads is:- BA.
NOTE: MOD.01 compasses must be modified to standard MOD.02 during repair
or overhaul. The additional components necessary for this modification are
detailed in TABLE 10001 below.
Item Description Qty Item Description Qty
70 Compensating
Ring
1 230 Lamp Housing
Assembly
1
130 Card Assembly 1 270 Label 1
180 Bowl 1
Components required for compass modification from
MOD.01 to MOD.02
TABLE 10001
PAGE 10001
APR 10/03
34-25-21
