Siruba FA007 - Page 23

REF. NO.部件編號
C1-01
C1-02
C1-03
C1-04
C1-04-1
C1-Y2
C1-C6
C1-07
C1-08
C1-09
C1-10
C1-11
C1-12
C1-13
C1-14
C1-15
C1-16
C1-17
C1-18
C1-18-1
C1-18-2
C1-18-3
C1-19
C1-21
C1-22
C1-22A
C1-23
C1-24
C1-25
C1-26
C1-27
C1-29
C1-30
C1-31
C1-102
C1-102-1
C1-X3
C1-X4
C1-X5
C1-X6
C1-X7
C1-X38-1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
2
3
2
2
2
1
1
2
1
1
1
1
1
1
4
1
2
2
PULL BAR ENDING SCREW 合葉螺釘
VERTICAL PULL BAR 傳動連桿
PULL BAR BEARING 滾柱軸承
VERTICAL PULL BAR FIXING SCREW 合葉螺釘
WASHER 墊圈
PULL BAR SCREW NUT 止動螺母
UPPER SHAFT 上主軸
BALL BEARING 6202 軸承
BEARING SUPPORT 軸墊圈
OIL STOPPER 油封
BEARING CASE ASSEMBLY 軸套筒
BEARING 6302 軸承
OIL TANK 儲油器
OILGAUGE WINDOW 油鏡
PACKING 油封墊圈
OIL GAUGE FLANGE 儲油器蓋
OIL TANK PACKING 止油銅墊圈
PACKING 橡膠墊圈
UPPER WHEEL ECCENTRIC WHEEL 偏心凸輪
ECCENTRIC WHEEL WASHER 凸輪蓋
BEARING 滾柱軸承
SCREW 9/64×40 螺釘
UPPER WHEEL MOVING PULL BAR 凸輪傳動連桿
PULL BAR SCREW NUT 合葉螺釘
FIXING PULL BAR SCREW WASHER 止滑墊圈
WASHER 墊圈(薄)
PULL BARSCREW NUT 螺母
THICKNESS ADJUSTING PULL BAR 擺動傳桿
PULL BAR FIXING PULL BAR 螺釘
UPPER WHEEL CONNECTION 傳動軸
MOVABLE LEFT-RIGHT CHOCK RING 定位圈
CONNECTION COPPER TUBE 銅套筒
VERTICAL PULL BAR 雙頭合葉螺釘
WASHER 墊圈
BEARING FIXING SCREW 外牙螺母
BEARING FIXING BUSHING 緊壓套筒
SCREW 15/64×28 螺釘
SCREW 15/64×28 螺釘
SCREW 9/64×40 螺釘
CAP SCREW 覆蓋螺釘
SCREW 1/4×28 螺釘
SCREW 11/64×40 螺釘
NAME OF PARTS 說明
Amt req需求量
UPPER SHAFT MACHANISM
~4~
