Siruba FA007 - Page 25

REF. NO.部件編號
C2-01
C2-02
C2-03
C2-04
C2-05
C2-C6
C2-07
C2-08
C2-09
C2-10
C2-11
C2-C12
C2-14
C2-C15
C2-16
C2-17
C2-18
C2-C19
C2-20
C2-C21-1
C2-22
C2-23
C2-24
C2-C25
C2-26
C2-X7
C2-X8
C2-X9
C2-X10
C2-X14
C2-X31-1
C2-X49
NEEDLE BAR CRANK 固定軸
NEEDLE BAR CRANK BOD 提升連桿
NEEDLE BAR BRACKET 針柱夾
WICK 油蕊
OIL LEAK PROOF CAP 防油蓋
WICK 油蕊
NEEDLE BAR GUIDE SLIDE BLOCK 四方滑塊
NEEDLE BAR GUIDE 導軌
NEEDLE BAR 針柱
NEEDLE BAR BUSHING (U) 針柱套筒(上)
NEEDLE BAR BUSHING (D)針柱套筒(下)
THREAD TAKE-UP CRANK 平衡凸塊
OIL CAP 橡膠塞
NEEDLE 針
FEED DOG ECCENTRIC AXLE 調節凸輪
WASHER 墊圈
ECCENTRIC WHEEL SLEEVE 銅滑塊
ECCENTRIC WHEEL WITH SCREW 上下凸輪
ECCENTRIC WHEEL SLEEVE 銅滑塊
FEED BAR SLIDE BLOCK ASSEMBLY 送布傳動曲柄
PACKING 油封墊圈
FEED LIFTING FORK 叉動柄
FEED BAR SLIDE BLOCK ASSEMBLY 四方滑塊
FEED BAR ECCENTRIC SHAFT 偏心軸
FEED DOG ECCENTRIC SET 固定座
SCREW1/4×40 螺釘
SCREW11/64×40 L12 螺釘
SCREW 15/64×28 螺釘
SCREW 15/64×28 螺釘
FEED ECCENTRIC ADJUSTING SCREW 導位螺釘
SCREW 9/64×40 螺釘
SCREW 9/64×40 L5 螺釘
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
4
4
5
2
1
1
1
1
NAME OF PARTS 說明
Amt req需求量
NEEDLE BAR MECHANISM-FEED MECHANISM
~6~
