Siruba FA007 - Page 29

REF. NO.部件編號
C4-C1
C4-02
C4-03
C4-04
C4-05
C4-06
C4-07
C4-08
C4-09
C4-10
C4-11
C4-12
C4-13
C4-14
C4-15
C4-16
C4-17
C4-B18
C4-19
C4-20
C4-24
C4-X8
C4-X9
C4-X25
C4-X26
C4-X27
C4-X31
C4-X44
C4-X60
C4-X95
C4-Y02
C4-D2-27
PRESSR BAR 壓腳柱
FACE PLATE UPPER HINGE ASSEMBLY 蝶型後鈕
STEEL BALL 鋼珠
PRESSER BAR BUSHING (UPPER) 壓腳柱軸套(上)
PRESSER BAR BUSHING (LOWER) 壓腳柱軸套(下)
FACE PLATE (LOWER) 前蓋板(下)
PACKING 防油墊片
PRESSER BAR CLAMP ASSEMBLY 壓腳柱夾
PRESSER BAR CLAMP SPRING 壓力板
PRESSER BAR CLAMP SPRING PIN 定位銷
PRESSER BAR CLAMP SPRING ASSEMBLY 上壓力彈片
GUIDE WASHER 定向墊片
WING NUT 蝶型螺母
PRESSER BAR LIFTER 壓腳提放勾
KNEE LIFTER LEVER 壓腳提放柄
KNEE LIFTER SPRING 壓腳提放彈簧
PRESSER FOOT LIFTER CHAIN ASSEMBLY 傳動鏈條
FACE PLATE (UPPER) 前上蓋
STOPPER SPRING PLATE (L) 彈片勾(外)
STOPPER SPRING PLATE (S) 彈片勾(內)
OIP CAP 油塞
SCREW11/64×40 螺釘
SCREW 15/64×28 螺釘
PRESSER ADJUSTING SCREW 全牙螺釘
STUD SCREW 15/64×28 螺釘
STUD SCREW 5/16×28 螺釘
SCREW 9/64×40 L10 螺釘
SCREW 9/64×40 螺釘
SCREW 9/64×40 螺釘
SCREW 9/64×40 螺釘
NUT 3/16×32 螺母
RUBBER PLUR 橡膠塞
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
3
4
1
1
1
1
NAME OF PARTS 說明
Amt req需求量
PRESSER BAR MECHANISM
~10~
