LEDS ON HANDHELD
The handheld is equipped with 3 LEDs used to indicate the functioning of the system. The various meanings are described in the following table.
BACKLIGHT: activates for 10sec. upon waking from standby (power saving) in low light conditions.
LED OPERATION MEANING
GREEN
Blinks 1 time A button is pressed
Blinks 6 times Lost radio link
Flashes every 5 sec. Sending radio signal (CloseLink)
YELLOW
SAFETYPOINT™ Fixed light Handheld out of magnetic range SafetyPointPlate at the push of a SafetyPoint™ button
PAGE
CHANGE
Blinks 1 time Selection of the 1st page or signals the key pressed is on the 1st page
Blinks 2 times Selection of the 2nd page or signals the key pressed is on the 2nd page
RED
Flashes While I press a key it indicates low battery
Fixed light While I press a key it indicates dead battery
80
