9
Connector type 160 for EV at mains voltage L = 1000 mm 0.960.103
Screw and gasket for connector type 160 0.960.104
Nut and olive for connection to pilot burner with pipe: ø 4 mm 0.958.030
ø 6 mm 0.958.031
ø 1/4 0.958.032
Millivolt generator 450 mm (19") 0.240.001
Millivolt generator 600 mm (23") 0.240.002
LPG pilot for mV versions 0.190.601
NG pilot for mV versions 0.190.602
Piezo-igniter 0.073.953
Support for piezo-igniter 0.978.099
Support fixing screw 0.953.303
Pressure regulator override device 0.907.037
Control knob extension 0.916.169
Adjustment knob extension 0.916.189
Other accessories are available on request
ACCESSOIRES
MAINTENANCE
The only maintenance operation permitted is the replacement of the magnet unit and, for AC-powered versions, the
coil of the automatic shut-off valve.
The operation must be carried out by qualified personnel only and according to the instructions provided with the
spare parts.
