ELECTRICAL DATA
MAIN OPERATOR SPECIFICATIONS
Minimum open circuit voltage ≥ 325mV
Minimum closed circuit voltage ≥ 100mV
Operator resistance 2.25Ω ± 0.5Ω
SAFETY MAGNET SPECIFICATIONS
Coil resistance 0.015Ω ~ 0.021Ω
TYPICAL HOLD IN AND DROP OUT SPECIFICATIONS
Hold In Drop Out
True Millivolt <10mA >4mA
Millivolt Plus <285mA >125mA
Vent Free <200mA >80mA
STOP:
Do not install, replace, or in any way modify the gas valve or the appliance, unless
CERTIFIED and QUALIFIED as a Gas Appliance Service Technician on the appliance this
valve is used on. READ AND FOLLOW ALL INSTRUCTIONS.
INSTALLATION
When installation of this product begins…
1. Read all of these instructions carefully. Failure to follow these instructions could damage the
product or cause a dangerous condition.
2. Check the ratings given in the instructions and on the appliance to make certain that the control
is suitable for your application.
3. All operations of installation, calibration, conversion and regulation must be undertaken
exclusively by a qualified and certified Gas Appliance Service Technician following the
instruction specified in this catalog and those in the instruction manual of the appliance in which
the valve is installed.
4. After installation is complete, verify that the appliance is operating as indicated in these
instructions.
WARNING:
Oxygen Depletion Hazard.
Can cause injury or death by asphyxiation.
Do not use valves for vented appliances on unvented or vent free appliances. Do not use
valves for unvented or vent free appliances on vented appliances.
