A2 mini User Manual V1.1
25
2023 SIYI Technology Co., Ltd, All Rights Reserved
5
uint8_t
get_temp_flag
0: Turn off temperature measuring
1: Measure the temperature once
2: Continuous temperature measuring
at 5 Hz
ACK data format
1
uint16_t
startx
X coordinate of the starting point of
the box
2
uint16_t
starty
Y coordinate of the starting point of
the box
3
uint16_t
endx
X coordinate of the ending point of the
box
4
uint16_t
endy
Y coordinate of the ending point of the
box
5
uint16_t
temp_max
Max temperature in the box / 100 (two
decimal places)
6
uint16_t
temp_min
Min temperature in the box / 100 (two
decimal places)
7
uint16_t
temp_max_x
X coordinate of the max temperature
in the box
8
uint16_t
temp_max_y
Y coordinate of the max temperature
in the box
9
uint16_t
temp_min_x
X coordinate of the min temperature in
the box
10
uint16_t
temp_min_x
Y coordinate of the min temperature in
the box
Mark:
1. Thermal camera supports digital zoom, the temperature measuring box will zoom in and out according to
the digital zoom. Under digital zoom, the temperature measuring range should refer to the box responded
by the camera.
2. Read temperature of a box command is only available for ZT30 at this moment.
Read Temperature of the Full Screen
CMD_ID:0x14------Read Temperature of the Full Screen
Send data format
No.
Data Type
Data Name
Description
1
uint8_t
get_temp_flag
0: Turn off temperature measuring
1: Measure the temperature once
2: Continuous temperature measuring
at 5 Hz
ACK data format
1
uint16_t
temp_max
Max temperature of the full screen /
100 (two decimal places)
2
uint16_t
temp_min
Min temperature of the full screen /
100 (two decimal places)
3
uint16_t
temp_max_x
X coordinate of the max temperature
in the full screen
4
uint16_t
temp_max_y
Y coordinate of the max temperature
in the full screen
5
uint16_t
temp_min_x
X coordinate of the min temperature in
