4.3 Output Video Stream to Windows Device through HM30 Full HD
Image Transmission System
Gimbal connects to HM30 air unit directly, then video will be displayed in SIYI QGC
Windows software when the air unit is communicating with the ground unit.
Please refer to chapter 3.4 of this manual for details.
4.4 Output to Third-Party Links
A2 mini gimbal can output video stream to third-party image transmission systems
which provide Ethernet port and are compatible with RTSP video stream.
In this way, it is necessary to prepare a customized link cable for connection
between SIYI gimbal camera and the third-party image transmission system.
CAUTION
The “RX-” pinout on SIYI gimbal’s video port should connect to the image transmission
system video port’s “RX-” pinout, and “RX+” pinout to “RX+” pinout. Do not cross the
pinouts, otherwise it will cause damage to the device.
Steps
1. Power the air unit of the image transmission system and bind it with the ground
unit.
