A2 mini User Manual V1.1
35
2023 SIYI Technology Co., Ltd, All Rights Reserved
Steps for SIYI QGC Windows
1. Power air unit and bind it with ground unit.
2. Connect the air unit’s Ethernet port to the gimbal.
3. Then use HM30 Ground Unit LAN to RJ45 cable to connect the ground unit’s
LAN port with the computer’s RJ45 port.
4. Modify the computer’s Ethernet settings to have the same gateway with SIYI
link and avoid IP addresses conflict.
For example, let’s assign “192.168.144.30” for the computer IP addresses.
5. Run SIYI QGC Windows software, go to “Comm Links – Video Settings”, and
select “RTSP Video Stream” for “Source”, then enter the default RTSP
addresses of SIYI gimbal camera, video stream will display. Gimbal motion and
camera functions can be controlled by mouse in QGroundControl.
