Water Purification System
WPUA900C / WPUA900F
CAUTION
•
Do not disassemble the product at your own discretion.
–
Doing so may result in fire or electric shock.
•
Be sure to use genuine SK Magic components (filters/fittings/tubing) and ask a professional
engineer to replace them.
–
Failure to do so may result in product failure or reduce the product life.
Source Water
Supply Valve
NOS Valve Pressure
Reduction
Valve
Instant Hot Water
Module
Step 1
Step 1
Sediment
Sediment
Step 2
Step 2
Block
Block
Carbon
Carbon
Composite
Composite
Step 3
Step 3
Nanotech
Nanotech
PAC
PAC
Flow Sensor
Ambient Temperature
Water Supply Valve
Source Water
Supply Valve
Cold Water
Supply
Valve
Hot Water
Supply
Valve
Direct and
Cold Water Pipe
90°
