Skan ErgoMeter - Parts and Tools List

37
Parts and tools list
PART NO. DESCRIPTION MATERIAL SPECIFICATION Q’TY
A Computer ABS SM2581-67 1
A-1 Screw for computer M5x10mm 4
B Axle set 1 Set
B-1 Screw M8x12mm 3
B-2 Driving wheel ABS 1
B-3 Sleeve 1
B-4 Axle 1
C Flywheel assembly 1 Set
C-1 Washer ø10xø17x1T 2
C-2 Nut 3/8“-26, 4,5T 5
C-3 Sleeve 1
C-4 Bearing 6900RS 1
C-5 Pulley 1
C-6 Bearing 6203RS 1
C-7 One-way bearing 1
C-8 Washer ø30xø34x1t 1
C-9 Bearing 6003RS 1
C-10 Bearing 6300RS 1
C-11 Axle for flywheel ø11,5x120L 1
C-12 Flywheel ø250x32W 1
C-13 Sleeve 1
D Idler wheel assembly 1 Set
D-1 Screw
M6xP1.0x12L
1
D-2 Idler wheel
ø24xø37x20.5mmL
1
D-3 Wave washer
ø10.5xø15x0.3t
2
D-4 Nut
M8
1
D-5 Screw
M8xP1.25x20L
1
D-6 Washer
ø8.5xø25x1t
1
D-7 Washer
ø6xø12x1t
1
D-8 Idler spring
1
E Screws for handlebars post 1 Set
E-1 Washer ø8xø19x2T 4
E-2 Screw M8x16mm 4
F Magnet set assembly 1 Set
F-1 Screw M6x16mm 2
F-2 Washer ø6 2
F-3 Washer ø6xø13x1t 2
G-1 Chain cover, right ABS 1
G-2 Crank, right 1
G-3 Screw M8x20mm 2
G-4 L/R Pedals (1xleft & 1xright) PP 1 Set
