Parts and tools list (followed)

PART NO. DESCRIPTION MATERIAL SPECIFICATION Q’TY

G-5 Self-tapping screw M4x50mm 7

G-6 Seat PVC 1

G-7 Chain cover, left ABS 1

G-8 Screw M4x12mm 8

G-9 Screw 3/16“x3/4“ 6

G-10 Decorative cover ABS 2

G-11 D/C wire with nut 1

G-12 Main frame 1

G-13 Bearing 6203RS 2

G-14 Wave washer ø17,5xø25x0.3t 1

G-15 Washer ø17,5xø25x0.3t 1

G-16 C-Ring ø17 1

G-17 Belt Rubber J6 1092mm 1

G-18 Sleeve for seat post PP 1

G-19 Pop pin ABS M16x27mm 1

G-20 Sensor cable, lower 800mm 1

G-21 Screw M4x10mm 1

G-22 Sensor-Box PE 1

G-23 Sensor holder PE 1

G-24 Cover for handlebars STR 1

G-25 Crank, left 1

G-26 Adaptor PPO

230V~50Hz, 9VDC 1.5A

1

H Handlebars post assembly 1 Set

H-1 Sensor cable, upper 950mm 1

H-2 Handlebars post 1

I Rear stabilizer assembly 1 Set

I-1 Screw 3/16“x3/4“ 4

I-2 End cap, left PP 1

I-3 Height adjusters 3/8“x30mm 2

I-4 End cap, right PP 1

I-5 Rear stabilizer 1

J Front stabilizer assembly 1 Set

J-1 End cap, left PP 1

J-2 Screw M8x40mm 2

J-3 Transportation roll Nylon 2

J-4 Nut M8 2

J-5 Washer ø8xø19x2T 2

J-6 End cap, right PP 1

J-7 Front stabilizer 1

J-8 Screw 3/16“ x 3/4" 4
