39
Parts and tools list (followed)
PART NO. DESCRIPTION MATERIAL SPECIFICATION Q’TY
K Seat post 1
L Seat slider assembly 1 Set
L-1 Seat slider 1
L-2 Fixing bracket 1
L-3 Knob ABS 7/16“x20L 1
L-4 Washer ø14,3xø25x2t 1
L-5 Cap for seat slider PVC 1
L-6 Cover, left ABS 1
L-7 Cover, right ABS 1
L-8 Screw M5x8mm 2
L-9 Self-tapping screw M4x12mm 1
M Handlebars assembly 1 Set
M-1 Foam grip PVC 2
M-2 Handpulse 2
M-3 Cap for handlebars STR 23mm 2
M-4 Handpulse cable 650+650mm 1
M-5 Screw M3x20mm 2
M-6 Handlebars 1
N Hardware set 1 Set
N-1 T-Screw ABS M8xP1.25x65L 1
N-2 Cover ABS 1
N-3 Screw M8x20mm 8
N-4 Washer ø8xø19x2t 8
N-5 Wrench 13/15/17 mm 1
N-6 Allen key 30 x 84 mm 1
N-7 Box spanner 13/14 mm 1
P Gear box 1
Hardware set:
