Assembly
Step 5: Handlebars
Assemble the handlebars (M-6) to the handlebars post (H-2) by the handlebars cover (N-2) and the
T-knob (N-1).
You may adjust the angular to your individual convenience before fixing the handlebars (M-6) tightly.
Pay attention not to squeeze the handpulse cables. Put the plastic caps onto both ends of the
handlebars (if not already premounted). Guide the handpulse cable (M-4) carefully through
the drilling hole of the handlebars post.
